claros® 50W Dental Laser

Product overview
Powerful diode laser for dental medicine
With up to 50 watts of power and variable pulsation
Particularly gentle on tissue thanks to low penetration depth
With autoclavable Ergo Flex Plus handpiece
Ensures secure cutting

claros® 50W Dental Laser
The innovative claros® 50W dental laser from elexxion is a powerful diode laser for dental medicine. With an application power of up to 50 W and variable pulsation, it is used in surgery, implantology, endodontics, periodontology and many other areas. It achieves an enormous cutting speed at a pulse rate of up to 20,000 Hz, which excludes carbonisation. Thanks to a low penetration depth, the dental laser is particularly gentle on the tissue.

In addition, the claros® 50W dental laser is equipped with an ergonomic multifunctional handpiece that fits comfortably in the hand and thus guarantees safe cutting. The Ergo Flex Plus handpiece is autoclavable and is compatible with economical application fibres that do not require cutting or splitting. The length of the fibres reduces with each use and lasts for up to 45 treatments.

Spare parts and accessories for the claros® dental lasers are available on request.

Product Details
claros® 50W Dental-Laser von elexxion
Powerful diode laser for dental medicine
With up to 50 watts of power and variable pulsation
Operates at a pulse rate of up to 20,000 Hz
Low risk of carbonisation
Particularly gentle on tissue thanks to low penetration depth
With ergonomic and autoclavable multifunctional handpiece
Ensures secure cutting
Handpiece can be combined with application fibres
Can be upgraded as required

Applications
Surgery: for haemostasis, hyperplasia, dull ridge or vestibuloplasty
Implantology: implant exposure, decontamination and peri-implantitis
Endodontics: germ reduction in the canal and retrograde, high penetration in the tubules
Periodontology: germ reduction in the pockets, removal of granulation tissue, decontamination of the membranes
Further applications: laser bleaching, pain therapy, aphthae, herpes, wound treatment, gag suppression, temporomandibular joint disorders

SNORE3: non-invasive anti-snoring therapy
Increases the quality of life and oxygen supply of your patients
Safe laser therapy without anaesthesia and pain
3 to 5 treatments of 25 minutes each are sufficient
Short treatment interval of 6 weeks
Complete healing within 18 weeks
Tightening of the soft palate thanks to an increase in collagen production
For dentists and ENT specialists

Technical Details
Mains connection: 230 V / 50 Hz
Power consumption: 1.5 A
Fuses: 1.6 A T according to IEC 60127-2/III (2 pieces)
Operating mode: Short-time duty - laser emission 2 min ON / 1 min OFF
Protection class: I Application part type B IP X0
Electromagnetic compatibility: Class A
Wavelengths: 810 nm +/- 10 nm
Pulse power: 50 W +/- 5 W
CW mode: 15 W +/- 2 W
Pulse rate: variable CW - 20,000 Hz
Pulse duration: 2.5 µs – CW
Target beam: 635 nm +/- 5 nm < 1 mW
Dimensions: 85 x 45 x 50 cm (H x W x D)
Weight: 22 kg
Laser class: 4

Delivery Contents
claros® 50W control unit
elexxion comfort tray holder incl. Tray
Power cable
Foot switch
Laser safety goggles
8 x metal tips
Bending tool (autoclavable)
Ergo Flex Plus handpiece (autoclavable)
Fibre rod T8 (autoclavable)
Activation key card for all applications
Laser warning sign
User manual
Starter kit with 9 long-lasting fibres (2x 200/ 2x 300/ 3x 400/ 2x 600 μm)
SNORE3 Software + Activation Key Card
SNORE3 rod
